Gard

In the modern world where human life is most important value, more and more Law Enforcement Agencies dealing in public security prefer to use less lethal weapons

LESS LETHAL WEAPONS USE
• In the modern world where human life is most important value, more and more Law Enforcement Agencies dealing in public security prefer to use less lethal weapons.
• One of the effective less lethal weapons is electronic control devices (ECD) – or in a simple words – Stun Gun.
• World statistics show that there are cases of ECD (Stun Gun) using with a fatal outcome.



3 Major reasons for fatal cases:
• Existing ECD technologies provide only 1 or 2 shots (without cartridge replacement) – leading to firearm use after 2 shots are unsuccessful (long cartridge replacement time from front side of the ECDs).
• 1 or 2 shots are not enough or ineffective (no disconnection of cables after each shot-shooting limits in different directions) in the event with more than one suspect – leading to the use of firearms.
• Exercising excessive and uncontrolled power – repeated and prolonged shocks.

These 3 issues destroy the whole idea of “less lethal” and the value of human life. ECD GARD was developed based on the advantages and disadvantages of existing technologies and operational requirements
of the security forces. Due to the technical features ECD GARD enables high efficiency and safety = Disabling a dangerous subject without causing irreversible damage to health.



Technical details
Performance characteristics
Electric power 10 W – Safe and effective
Pulse repetition frequency 90-120 Hz
Effective impulse length 75-90 μs
Voltage (no-load) 50 kV
Voltage on load 1 000 Om 800-1700 V (corresponding resistance of the human body)
Distance target engagement 4.5 and 6.5 meters (depending on the type of cartridge)
Batteries 12 V, rechargeable LiPol, 550 mAh
Cycles of operation at one charge min 150 (3 sec each)
Temperature range -20…+50˚С
Dimensions (L*H*W) 223*150*39 mm (width of the grip-handle: 28 mm)
Device weight (fully equipped) 600 g
Material highly durable, light weigh and reliable polymer
